Gas tank pressure sensor
General:
The main function of the gas tank pressure sensor is to measure the inside pressure changes of the fuel tank, which can easily find gas leakage in advance, or other abnormal pressure changes caused by vehicle breakdowns.
Technical Parameters:
| Pressure Range | |
| Operating | -3.75 to 1.25 kPa |
| Maximum | 75 kPa |
| Full Scale Accuracy | 5% |
| Temperature Range | |
| Operating | -40°C to 85 °C |
| Storage | -40°C to 125 °C |
| Electrical Characteristics | |
| Supply Voltage | 5.0 ± 0.1 V dc |
| Supply Current | <10 mA dc |
| Maximum Output Current | Sink 40 mA dc |
| Source 45 mA dc | |
| Output Impedance | 100 ohms |
| Output Voltage | 0.5 to 4.5 V dc |
| Response Time (1) | (10% to 90%) |
| 1.0 ms | |
Product Image:
